High-speed plug dryer PXC-15B

High-speed plug dryer, PXC-15B

1）technical parameter

1）

2）List of main components

The main structure is made of 304 stainless steel material and meets the GMP requirements.

The main components are all using internationally famous brand products.

The SIEMENS PLC and Proface touchscreen controls were used.

A variety of specifications of paper-paper, paper-plastic back seal desiccant roll.

Using YASKAWA servo motor to drive, accurate feed positioning.

Motor drives the material opening system to ensure stable tension and avoid packing and material cutting.

Determine the desiccant length automatically and display the parameters on the touch screen for easy setting.

Use synchronous clamp belt drive to ensure constant cutting site desiccant form.

The cutting position is approved by using the U-type electric eye positioning device and the preset parameter alignment system.

A desiccant drop detection device is configured to verify the whereabouts of desiccant while the bottle stays into the station.

The desiccant color mark detection system can be configured to check the location of the package (optional).

Dual electric eye anti-cutting packet detection system can be configured (optional).

The packet breaking camera detection system can be configured to detect whether it is cut out (optional)

The tray putter removal mechanism can be configured (optional).

The rotary handle adjusts the lift rack to different bottle heights.

The cutter is driven by an SMC cylinder.

3）List of main components

(The above list may vary slightly to the use of other brand products of the same level)
